Description
Product Features
- Patented Havis Rugged keyboard mount
- Designed to mount Havis rugged USB backlit keyboards
- Front-access trigger permits easy fore/aft adjustment within a range of 3.875″
- Easily remove the keyboard using our unique quick-release push button
- Made of high performance PC-ABS thermoplastics resulting in outstanding strength, heat resistance, feature definition, and surface finish
- Primary mounting plate is glass fiber polymer reinforced for extra durability
- Mounting: VESA 75 at bottom of keyboard mount
- Use C-ADP-112 if mounting to flex arm mount
Product Specs
- Dimensions: 9.2″ ( 23.4 cm) h x 6.4″ ( 16.3 cm ) w x 1.4″ ( 3.6 cm ) d
- Testing: Vibration Testing: MIL-STD 810G 514.5, crash test: SAE J1455 30mph Crash Testing, environmental testing: hot/cold operational & storage
- Product weight: 1.0 lbs. (0.45 kg)
User Manuals and Installation Instructions
View C-KBM-201 Manual
Availability, Lead Times and Shipping
Please note that ALL Gamber-Johnson and Havis mounting and docking equipment typically takes at least a week to ship. Lead times can often be 3-6+ weeks or longer depending on the exact items purchased. The following is guidance only and changes frequently.
- Basic mounting hardware such as plates or poles: 1-2 weeks to ship
- Vehicle-specific kits or more complex mounting solutions: 2-4 weeks to ship
- Powered docking stations with port replication: 4-8+ weeks to ship.
Please call, email, or chat with us to discuss lead times as it specifically relates to your needs. Expedited shipping methods selected at checkout do not speed up lead times but rather reduce transit time when an order ships.
